Go to the source code of this file.
Defines | |
| #define | ARRAYSIZE(p) (sizeof(p)/sizeof(p[0])) |
| TO BE DOCUMENTED. | |
| #define | ARRAYSIZE(p) (sizeof(p)/sizeof(p[0])) |
| #define | END_RUNONCE __RunOnce__ = true;}} |
| #define | END_RUNONCE __RunOnce__ = true;}} |
| #define | IS_ALIGNED_2(x) ((x&1)==0) |
| #define | IS_ALIGNED_2(x) ((x&1)==0) |
| #define | IS_ALIGNED_4(x) ((x&3)==0) |
| #define | IS_ALIGNED_4(x) ((x&3)==0) |
| #define | IS_ALIGNED_8(x) ((x&7)==0) |
| #define | IS_ALIGNED_8(x) ((x&7)==0) |
| #define | OFFSET_OF(Class, Member) (size_t)&(((Class*)0)->Member) |
| TO BE DOCUMENTED. | |
| #define | OFFSET_OF(Class, Member) (size_t)&(((Class*)0)->Member) |
| #define | PREVENT_COPY(cur_class) private: cur_class(const cur_class& object); cur_class& operator=(const cur_class& object); |
| #define | PREVENT_COPY(cur_class) private: cur_class(const cur_class& object); cur_class& operator=(const cur_class& object); |
| #define | START_RUNONCE { static bool __RunOnce__ = false; if(!__RunOnce__){ |
| #define | START_RUNONCE { static bool __RunOnce__ = false; if(!__RunOnce__){ |
Functions | |
| inline_ void | _prefetch (void const *ptr) |
| inline_ udword | abs_ (sdword x) |
| Alternative min function. | |
| FUNCTION ICECORE_API udword | Alignment (udword address) |
| inline_ int | ClampToInt16 (int x) |
| inline_ void | Compute2DCoords (udword &u, udword &v, udword i, udword nbu) |
| inline_ void | Compute3DCoords (udword &u, udword &v, udword &w, udword i, udword nbu, udword nbu_nbv) |
| inline_ udword | CountBits (udword n) |
| Count the number of '1' bits in a 32 bit word (from Steve Baker's Cute Code Collection) | |
| inline_ udword | CountBits2 (udword bits) |
| Even faster? | |
| inline_ float | FeedbackFilter (float val, float &memory, float sharpness) |
| inline_ BOOL | HasNullByte (udword x) |
| inline_ bool | IsPowerOfTwo (udword n) |
| Test to see if a number is an exact power of two (from Steve Baker's Cute Code Collection) | |
| inline_ char | LittleEndian () |
| Alternative abs function. | |
| inline_ udword | LowestOneBit (udword w) |
| inline_ sdword | min_ (sdword a, sdword b) |
| inline_ udword | msb32 (udword x) |
| inline_ udword | nlpo2 (udword x) |
| inline_ void | ReverseBits (udword &n) |
| inline_ void | SetLeastNBits (udword &x, udword n) |
| Set the least significant N bits in a word. (from Steve Baker's Cute Code Collection) | |
| inline_ void | SpreadBits (udword &n) |
| *inline_ void | Swap (udword &x, udword &y) |
| template<class Type > | |
| inline_ Type | TClamp (const Type &x, const Type &lo, const Type &hi) |
| template<class Type > | |
| inline_ void | TSort (Type &a, Type &b) |
| template<class Type > | |
| inline_ void | TSort (Type &a, Type &b, Type &c) |
| template<class Type > | |
| inline_ void | TSwap (Type &a, Type &b) |
| inline_ void | ZeroLeastSetBit (udword &n) |
| Zero the least significant '1' bit in a word. (from Steve Baker's Cute Code Collection) | |
Variables | |
| x = y | |
| y = x | |
Detailed Description
Define Documentation
| #define ARRAYSIZE | ( | p | ) | (sizeof(p)/sizeof(p[0])) |
TO BE DOCUMENTED.
Definition at line 208 of file OPC_IceHook.h.
| #define ARRAYSIZE | ( | p | ) | (sizeof(p)/sizeof(p[0])) |
| #define END_RUNONCE __RunOnce__ = true;}} |
Definition at line 17 of file OPC_IceHook.h.
| #define END_RUNONCE __RunOnce__ = true;}} |
| #define IS_ALIGNED_2 | ( | x | ) | ((x&1)==0) |
Definition at line 220 of file OPC_IceHook.h.
| #define IS_ALIGNED_2 | ( | x | ) | ((x&1)==0) |
| #define IS_ALIGNED_4 | ( | x | ) | ((x&3)==0) |
Definition at line 221 of file OPC_IceHook.h.
| #define IS_ALIGNED_4 | ( | x | ) | ((x&3)==0) |
| #define IS_ALIGNED_8 | ( | x | ) | ((x&7)==0) |
Definition at line 222 of file OPC_IceHook.h.
| #define IS_ALIGNED_8 | ( | x | ) | ((x&7)==0) |
| #define OFFSET_OF | ( | Class, | |
| Member | |||
| ) | (size_t)&(((Class*)0)->Member) |
TO BE DOCUMENTED.
Definition at line 206 of file OPC_IceHook.h.
| #define OFFSET_OF | ( | Class, | |
| Member | |||
| ) | (size_t)&(((Class*)0)->Member) |
| #define PREVENT_COPY | ( | cur_class | ) | private: cur_class(const cur_class& object); cur_class& operator=(const cur_class& object); |
| #define PREVENT_COPY | ( | cur_class | ) | private: cur_class(const cur_class& object); cur_class& operator=(const cur_class& object); |
Definition at line 203 of file OPC_IceHook.h.
| #define START_RUNONCE { static bool __RunOnce__ = false; if(!__RunOnce__){ |
Definition at line 16 of file OPC_IceHook.h.
| #define START_RUNONCE { static bool __RunOnce__ = false; if(!__RunOnce__){ |
Function Documentation
Alternative min function.
Definition at line 118 of file IceUtils.h.
| FUNCTION ICECORE_API udword Alignment | ( | udword | address | ) |
| inline_ int ClampToInt16 | ( | int | x | ) |
If you can guarantee that your input domain (i.e. value of x) is slightly limited (abs(x) must be < ((1<<31u)-32767)), then you can use the following code to clamp the resulting value into [-32768,+32767] range:
Definition at line 171 of file IceUtils.h.
Definition at line 238 of file IceUtils.h.
| inline_ void Compute3DCoords | ( | udword & | u, |
| udword & | v, | ||
| udword & | w, | ||
| udword | i, | ||
| udword | nbu, | ||
| udword | nbu_nbv | ||
| ) |
Definition at line 250 of file IceUtils.h.
Count the number of '1' bits in a 32 bit word (from Steve Baker's Cute Code Collection)
Definition at line 32 of file IceUtils.h.
| inline_ udword CountBits2 | ( | udword | bits | ) |
Even faster?
Definition at line 49 of file IceUtils.h.
| inline_ float FeedbackFilter | ( | float | val, |
| float & | memory, | ||
| float | sharpness | ||
| ) |
Definition at line 160 of file IceUtils.h.
| inline_ BOOL HasNullByte | ( | udword | x | ) |
Definition at line 124 of file IceUtils.h.
| inline_ bool IsPowerOfTwo | ( | udword | n | ) |
Test to see if a number is an exact power of two (from Steve Baker's Cute Code Collection)
Definition at line 87 of file IceUtils.h.
| inline_ char LittleEndian | ( | ) |
Alternative abs function.
Little/Big endian (from Steve Baker's Cute Code Collection)
Extra comments by Kenny Hoff: Determines the byte-ordering of the current machine (little or big endian) by setting an integer value to 1 (so least significant bit is now 1); take the address of the int and cast to a byte pointer (treat integer as an array of four bytes); check the value of the first byte (must be 0 or 1). If the value is 1, then the first byte least significant byte and this implies LITTLE endian. If the value is 0, the first byte is the most significant byte, BIG endian. Examples: integer 1 on BIG endian: 00000000 00000000 00000000 00000001 integer 1 on LITTLE endian: 00000001 00000000 00000000 00000000 --------------------------------------------------------------------------- int IsLittleEndian() { int x=1; return ( ((char*)(&x))[0] ); }
Definition at line 115 of file IceUtils.h.
| inline_ udword LowestOneBit | ( | udword | w | ) |
Definition at line 127 of file IceUtils.h.
| inline_ void ReverseBits | ( | udword & | n | ) |
Reverse all the bits in a 32 bit word (from Steve Baker's Cute Code Collection) (each line can be done in any order.
Definition at line 20 of file IceUtils.h.
| inline_ void SetLeastNBits | ( | udword & | x, |
| udword | n | ||
| ) |
Set the least significant N bits in a word. (from Steve Baker's Cute Code Collection)
Definition at line 93 of file IceUtils.h.
| inline_ void SpreadBits | ( | udword & | n | ) |
Spread out bits. EG 00001111 -> 0101010101 00001010 -> 0100010000 This is used to interleve to intergers to produce a `Morten Key' used in Space Filling Curves (See DrDobbs Journal, July 1999) Order is important.
Definition at line 62 of file IceUtils.h.
Definition at line 184 of file IceUtils.h.
Definition at line 186 of file IceUtils.h.
Definition at line 191 of file IceUtils.h.
Definition at line 183 of file IceUtils.h.
| inline_ void ZeroLeastSetBit | ( | udword & | n | ) |
Zero the least significant '1' bit in a word. (from Steve Baker's Cute Code Collection)
Definition at line 90 of file IceUtils.h.
Variable Documentation
Definition at line 98 of file IceUtils.h.
Classic XOR swap (from Steve Baker's Cute Code Collection) x ^= y; /* x' = (x^y)
Definition at line 97 of file IceUtils.h.
