Base class for triangular part in a matrix. More...
#include <TriangularMatrix.h>
Public Types | |
| enum | { Mode = _Mode, TransposeMode } |
| typedef TriangularBase < TriangularView > | Base |
| typedef internal::traits < TriangularView > ::DenseMatrixType | DenseMatrixType |
| typedef internal::traits < TriangularView >::Index | Index |
| typedef _MatrixType | MatrixType |
| typedef DenseMatrixType | PlainObject |
| typedef internal::traits < TriangularView >::Scalar | Scalar |
| typedef internal::traits < TriangularView > ::StorageKind | StorageKind |
Public Member Functions | |
| const TriangularView< const typename MatrixType::AdjointReturnType, TransposeMode > | adjoint () const |
| template<typename ProductDerived , typename _Lhs , typename _Rhs > | |
| TriangularView< MatrixType, UpLo > & | assignProduct (const ProductBase< ProductDerived, _Lhs, _Rhs > &prod, const Scalar &alpha) |
| Scalar | coeff (Index row, Index col) const |
| Scalar & | coeffRef (Index row, Index col) |
| Index | cols () const |
| TriangularView < MatrixConjugateReturnType, Mode > | conjugate () |
| const TriangularView < MatrixConjugateReturnType, Mode > | conjugate () const |
| Scalar | determinant () const |
| void | fill (const Scalar &value) |
| Index | innerStride () const |
| template<typename OtherDerived > | |
| void | lazyAssign (const TriangularBase< OtherDerived > &other) |
| template<typename OtherDerived > | |
| void | lazyAssign (const MatrixBase< OtherDerived > &other) |
| const MatrixTypeNestedCleaned & | nestedExpression () const |
| MatrixTypeNestedCleaned & | nestedExpression () |
| template<typename OtherDerived > | |
| TriangularProduct< Mode, true, MatrixType, false, OtherDerived, OtherDerived::IsVectorAtCompileTime > | operator* (const MatrixBase< OtherDerived > &rhs) const |
| TriangularView & | operator*= (const typename internal::traits< MatrixType >::Scalar &other) |
| template<typename Other > | |
| TriangularView & | operator+= (const DenseBase< Other > &other) |
| template<typename ProductDerived , typename Lhs , typename Rhs > | |
| EIGEN_STRONG_INLINE TriangularView & | operator+= (const ProductBase< ProductDerived, Lhs, Rhs > &other) |
| template<typename ProductDerived > | |
| EIGEN_STRONG_INLINE TriangularView & | operator+= (const ScaledProduct< ProductDerived > &other) |
| template<typename Other > | |
| TriangularView & | operator-= (const DenseBase< Other > &other) |
| template<typename ProductDerived , typename Lhs , typename Rhs > | |
| EIGEN_STRONG_INLINE TriangularView & | operator-= (const ProductBase< ProductDerived, Lhs, Rhs > &other) |
| template<typename ProductDerived > | |
| EIGEN_STRONG_INLINE TriangularView & | operator-= (const ScaledProduct< ProductDerived > &other) |
| TriangularView & | operator/= (const typename internal::traits< MatrixType >::Scalar &other) |
| template<typename OtherDerived > | |
| TriangularView & | operator= (const TriangularBase< OtherDerived > &other) |
| template<typename OtherDerived > | |
| TriangularView & | operator= (const MatrixBase< OtherDerived > &other) |
| TriangularView & | operator= (const TriangularView &other) |
| template<typename ProductDerived , typename Lhs , typename Rhs > | |
| EIGEN_STRONG_INLINE TriangularView & | operator= (const ProductBase< ProductDerived, Lhs, Rhs > &other) |
| template<typename ProductDerived > | |
| EIGEN_STRONG_INLINE TriangularView & | operator= (const ScaledProduct< ProductDerived > &other) |
| Index | outerStride () const |
| Index | rows () const |
| const SelfAdjointView < MatrixTypeNestedNonRef, Mode > | selfadjointView () const |
| SelfAdjointView < MatrixTypeNestedNonRef, Mode > | selfadjointView () |
| TriangularView & | setConstant (const Scalar &value) |
| TriangularView & | setOnes () |
| TriangularView & | setZero () |
| template<int Side, typename Other > | |
| const internal::triangular_solve_retval < Side, TriangularView, Other > | solve (const MatrixBase< Other > &other) const |
| template<typename Other > | |
| const internal::triangular_solve_retval < OnTheLeft, TriangularView, Other > | solve (const MatrixBase< Other > &other) const |
| template<int Side, typename OtherDerived > | |
| void | solveInPlace (const MatrixBase< OtherDerived > &other) const |
| template<typename OtherDerived > | |
| void | solveInPlace (const MatrixBase< OtherDerived > &other) const |
| template<typename OtherDerived > | |
| void | swap (TriangularBase< OtherDerived > const &other) |
| template<typename OtherDerived > | |
| void | swap (MatrixBase< OtherDerived > const &other) |
| TriangularView< Transpose < MatrixType >, TransposeMode > | transpose () |
| const TriangularView < Transpose< MatrixType > , TransposeMode > | transpose () const |
| TriangularView (const MatrixType &matrix) | |
Protected Types | |
| typedef internal::remove_all < typename MatrixType::ConjugateReturnType > ::type | MatrixConjugateReturnType |
| typedef internal::traits < TriangularView > ::MatrixTypeNested | MatrixTypeNested |
| typedef internal::traits < TriangularView > ::MatrixTypeNestedCleaned | MatrixTypeNestedCleaned |
| typedef internal::traits < TriangularView > ::MatrixTypeNestedNonRef | MatrixTypeNestedNonRef |
Protected Member Functions | |
| template<typename ProductDerived , typename Lhs , typename Rhs > | |
| EIGEN_STRONG_INLINE TriangularView & | assignProduct (const ProductBase< ProductDerived, Lhs, Rhs > &prod, const Scalar &alpha) |
Protected Attributes | |
| MatrixTypeNested | m_matrix |
Friends | |
| template<typename OtherDerived > | |
| TriangularProduct< Mode, false, OtherDerived, OtherDerived::IsVectorAtCompileTime, MatrixType, false > | operator* (const MatrixBase< OtherDerived > &lhs, const TriangularView &rhs) |
Detailed Description
template<typename _MatrixType, unsigned int _Mode>
class Eigen::TriangularView< _MatrixType, _Mode >
Base class for triangular part in a matrix.
- Parameters:
-
MatrixType the type of the object in which we are taking the triangular part Mode the kind of triangular matrix expression to construct. Can be Upper, Lower, UnitUpper, UnitLower, StrictlyUpper, or StrictlyLower. This is in fact a bit field; it must have either Upper or Lower, and additionnaly it may have UnitDiag or ZeroDiag or neither.
This class represents a triangular part of a matrix, not necessarily square. Strictly speaking, for rectangular matrices one should speak of "trapezoid" parts. This class is the return type of MatrixBase::triangularView() and most of the time this is the only way it is used.
- See also:
- MatrixBase::triangularView()
Definition at line 158 of file TriangularMatrix.h.
Member Typedef Documentation
| typedef TriangularBase<TriangularView> Eigen::TriangularView< _MatrixType, _Mode >::Base |
Definition at line 163 of file TriangularMatrix.h.
| typedef internal::traits<TriangularView>::DenseMatrixType Eigen::TriangularView< _MatrixType, _Mode >::DenseMatrixType |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 167 of file TriangularMatrix.h.
| typedef internal::traits<TriangularView>::Index Eigen::TriangularView< _MatrixType, _Mode >::Index |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 182 of file TriangularMatrix.h.
typedef internal::remove_all<typename MatrixType::ConjugateReturnType>::type Eigen::TriangularView< _MatrixType, _Mode >::MatrixConjugateReturnType [protected] |
Definition at line 175 of file TriangularMatrix.h.
| typedef _MatrixType Eigen::TriangularView< _MatrixType, _Mode >::MatrixType |
Definition at line 166 of file TriangularMatrix.h.
typedef internal::traits<TriangularView>::MatrixTypeNested Eigen::TriangularView< _MatrixType, _Mode >::MatrixTypeNested [protected] |
Definition at line 171 of file TriangularMatrix.h.
typedef internal::traits<TriangularView>::MatrixTypeNestedCleaned Eigen::TriangularView< _MatrixType, _Mode >::MatrixTypeNestedCleaned [protected] |
Definition at line 173 of file TriangularMatrix.h.
typedef internal::traits<TriangularView>::MatrixTypeNestedNonRef Eigen::TriangularView< _MatrixType, _Mode >::MatrixTypeNestedNonRef [protected] |
Definition at line 172 of file TriangularMatrix.h.
| typedef DenseMatrixType Eigen::TriangularView< _MatrixType, _Mode >::PlainObject |
Definition at line 168 of file TriangularMatrix.h.
| typedef internal::traits<TriangularView>::Scalar Eigen::TriangularView< _MatrixType, _Mode >::Scalar |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 164 of file TriangularMatrix.h.
| typedef internal::traits<TriangularView>::StorageKind Eigen::TriangularView< _MatrixType, _Mode >::StorageKind |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 181 of file TriangularMatrix.h.
Member Enumeration Documentation
| anonymous enum |
Definition at line 184 of file TriangularMatrix.h.
Constructor & Destructor Documentation
| Eigen::TriangularView< _MatrixType, _Mode >::TriangularView | ( | const MatrixType & | matrix | ) | [inline] |
Definition at line 192 of file TriangularMatrix.h.
Member Function Documentation
| const TriangularView<const typename MatrixType::AdjointReturnType,TransposeMode> Eigen::TriangularView< _MatrixType, _Mode >::adjoint | ( | ) | const [inline] |
- See also:
- MatrixBase::adjoint() const
Definition at line 264 of file TriangularMatrix.h.
| TriangularView<MatrixType,UpLo>& Eigen::TriangularView< _MatrixType, _Mode >::assignProduct | ( | const ProductBase< ProductDerived, _Lhs, _Rhs > & | prod, |
| const Scalar & | alpha | ||
| ) |
Definition at line 269 of file GeneralMatrixMatrixTriangular.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::assignProduct | ( | const ProductBase< ProductDerived, Lhs, Rhs > & | prod, |
| const Scalar & | alpha | ||
| ) | [protected] |
| Scalar Eigen::TriangularView< _MatrixType, _Mode >::coeff | ( | Index | row, |
| Index | col | ||
| ) | const [inline] |
- See also:
- MatrixBase::coeff()
- Warning:
- the coordinates must fit into the referenced triangular part
Definition at line 222 of file TriangularMatrix.h.
| Scalar& Eigen::TriangularView< _MatrixType, _Mode >::coeffRef | ( | Index | row, |
| Index | col | ||
| ) | [inline] |
- See also:
- MatrixBase::coeffRef()
- Warning:
- the coordinates must fit into the referenced triangular part
Definition at line 231 of file TriangularMatrix.h.
| Index Eigen::TriangularView< _MatrixType, _Mode >::cols | ( | void | ) | const [inline] |
- Returns:
- the number of columns.
- See also:
- rows(), ColsAtCompileTime
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 196 of file TriangularMatrix.h.
| TriangularView<MatrixConjugateReturnType,Mode> Eigen::TriangularView< _MatrixType, _Mode >::conjugate | ( | ) | [inline] |
- See also:
- MatrixBase::conjugate()
Definition at line 257 of file TriangularMatrix.h.
| const TriangularView<MatrixConjugateReturnType,Mode> Eigen::TriangularView< _MatrixType, _Mode >::conjugate | ( | ) | const [inline] |
- See also:
- MatrixBase::conjugate() const
Definition at line 260 of file TriangularMatrix.h.
| Scalar Eigen::TriangularView< _MatrixType, _Mode >::determinant | ( | ) | const [inline] |
Definition at line 368 of file TriangularMatrix.h.
| void Eigen::TriangularView< _MatrixType, _Mode >::fill | ( | const Scalar & | value | ) | [inline] |
- See also:
- MatrixBase::fill()
Definition at line 210 of file TriangularMatrix.h.
| Index Eigen::TriangularView< _MatrixType, _Mode >::innerStride | ( | ) | const [inline] |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 198 of file TriangularMatrix.h.
| void Eigen::TriangularView< MatrixType, Mode >::lazyAssign | ( | const TriangularBase< OtherDerived > & | other | ) |
Definition at line 647 of file TriangularMatrix.h.
| void Eigen::TriangularView< MatrixType, Mode >::lazyAssign | ( | const MatrixBase< OtherDerived > & | other | ) |
Definition at line 610 of file TriangularMatrix.h.
| const MatrixTypeNestedCleaned& Eigen::TriangularView< _MatrixType, _Mode >::nestedExpression | ( | ) | const [inline] |
Definition at line 237 of file TriangularMatrix.h.
| MatrixTypeNestedCleaned& Eigen::TriangularView< _MatrixType, _Mode >::nestedExpression | ( | ) | [inline] |
Definition at line 238 of file TriangularMatrix.h.
| TriangularProduct<Mode,true,MatrixType,false,OtherDerived, OtherDerived::IsVectorAtCompileTime> Eigen::TriangularView< _MatrixType, _Mode >::operator* | ( | const MatrixBase< OtherDerived > & | rhs | ) | const [inline] |
Efficient triangular matrix times vector/matrix product
Definition at line 282 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator*= | ( | const typename internal::traits< MatrixType >::Scalar & | other | ) | [inline] |
- See also:
- MatrixBase::operator*=()
Definition at line 205 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator+= | ( | const DenseBase< Other > & | other | ) | [inline] |
- See also:
- MatrixBase::operator+=()
Definition at line 201 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator+= | ( | const ProductBase< ProductDerived, Lhs, Rhs > & | other | ) | [inline] |
Definition at line 387 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator+= | ( | const ScaledProduct< ProductDerived > & | other | ) | [inline] |
Definition at line 407 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator-= | ( | const DenseBase< Other > & | other | ) | [inline] |
- See also:
- MatrixBase::operator-=()
Definition at line 203 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator-= | ( | const ProductBase< ProductDerived, Lhs, Rhs > & | other | ) | [inline] |
Definition at line 393 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator-= | ( | const ScaledProduct< ProductDerived > & | other | ) | [inline] |
Definition at line 413 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator/= | ( | const typename internal::traits< MatrixType >::Scalar & | other | ) | [inline] |
- See also:
- MatrixBase::operator/=()
Definition at line 207 of file TriangularMatrix.h.
| TriangularView< MatrixType, Mode > & Eigen::TriangularView< MatrixType, Mode >::operator= | ( | const TriangularBase< OtherDerived > & | other | ) | [inline] |
Assigns a triangular matrix to a triangular part of a dense matrix
Definition at line 631 of file TriangularMatrix.h.
| TriangularView< MatrixType, Mode > & Eigen::TriangularView< MatrixType, Mode >::operator= | ( | const MatrixBase< OtherDerived > & | other | ) | [inline] |
Definition at line 594 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator= | ( | const TriangularView< _MatrixType, _Mode > & | other | ) | [inline] |
Definition at line 247 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator= | ( | const ProductBase< ProductDerived, Lhs, Rhs > & | other | ) | [inline] |
Definition at line 380 of file TriangularMatrix.h.
| EIGEN_STRONG_INLINE TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::operator= | ( | const ScaledProduct< ProductDerived > & | other | ) | [inline] |
Definition at line 400 of file TriangularMatrix.h.
| Index Eigen::TriangularView< _MatrixType, _Mode >::outerStride | ( | ) | const [inline] |
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 197 of file TriangularMatrix.h.
| Index Eigen::TriangularView< _MatrixType, _Mode >::rows | ( | void | ) | const [inline] |
- Returns:
- the number of rows.
- See also:
- cols(), RowsAtCompileTime
Reimplemented from Eigen::TriangularBase< TriangularView< _MatrixType, _Mode > >.
Definition at line 195 of file TriangularMatrix.h.
| const SelfAdjointView<MatrixTypeNestedNonRef,Mode> Eigen::TriangularView< _MatrixType, _Mode >::selfadjointView | ( | ) | const [inline] |
Definition at line 344 of file TriangularMatrix.h.
| SelfAdjointView<MatrixTypeNestedNonRef,Mode> Eigen::TriangularView< _MatrixType, _Mode >::selfadjointView | ( | ) | [inline] |
Definition at line 349 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::setConstant | ( | const Scalar & | value | ) | [inline] |
- See also:
- MatrixBase::setConstant()
Definition at line 212 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::setOnes | ( | ) | [inline] |
- See also:
- MatrixBase::setOnes()
Definition at line 217 of file TriangularMatrix.h.
| TriangularView& Eigen::TriangularView< _MatrixType, _Mode >::setZero | ( | ) | [inline] |
- See also:
- MatrixBase::setZero()
Definition at line 215 of file TriangularMatrix.h.
| const internal::triangular_solve_retval< Side, TriangularView< Derived, Mode >, Other > Eigen::TriangularView< Derived, Mode >::solve | ( | const MatrixBase< Other > & | other | ) | const [inline] |
- Returns:
- the product of the inverse of
*thiswith other, *this being triangular.
This function computes the inverse-matrix matrix product inverse(*this) * other if Side==OnTheLeft (the default), or the right-inverse-multiply other * inverse(*this) if Side==OnTheRight.
The matrix *this must be triangular and invertible (i.e., all the coefficients of the diagonal must be non zero). It works as a forward (resp. backward) substitution if *this is an upper (resp. lower) triangular matrix.
Example:
This function returns an expression of the inverse-multiply and can works in-place if it is assigned to the same matrix or vector other.
For users coming from BLAS, this function (and more specifically solveInPlace()) offer all the operations supported by the *TRSV and *TRSM BLAS routines.
- See also:
- TriangularView::solveInPlace()
Definition at line 216 of file SolveTriangular.h.
| const internal::triangular_solve_retval<OnTheLeft,TriangularView, Other> Eigen::TriangularView< _MatrixType, _Mode >::solve | ( | const MatrixBase< Other > & | other | ) | const [inline] |
Definition at line 337 of file TriangularMatrix.h.
| void Eigen::TriangularView< MatrixType, Mode >::solveInPlace | ( | const MatrixBase< OtherDerived > & | _other | ) | const |
"in-place" version of TriangularView::solve() where the result is written in other
- Warning:
- The parameter is only marked 'const' to make the C++ compiler accept a temporary expression here. This function will const_cast it, so constness isn't honored here.
See TriangularView:solve() for the details.
Definition at line 174 of file SolveTriangular.h.
| void Eigen::TriangularView< _MatrixType, _Mode >::solveInPlace | ( | const MatrixBase< OtherDerived > & | other | ) | const [inline] |
Definition at line 341 of file TriangularMatrix.h.
| void Eigen::TriangularView< _MatrixType, _Mode >::swap | ( | TriangularBase< OtherDerived > const & | other | ) | [inline] |
Definition at line 356 of file TriangularMatrix.h.
| void Eigen::TriangularView< _MatrixType, _Mode >::swap | ( | MatrixBase< OtherDerived > const & | other | ) | [inline] |
Definition at line 362 of file TriangularMatrix.h.
| TriangularView<Transpose<MatrixType>,TransposeMode> Eigen::TriangularView< _MatrixType, _Mode >::transpose | ( | ) | [inline] |
- See also:
- MatrixBase::transpose()
Definition at line 268 of file TriangularMatrix.h.
| const TriangularView<Transpose<MatrixType>,TransposeMode> Eigen::TriangularView< _MatrixType, _Mode >::transpose | ( | ) | const [inline] |
- See also:
- MatrixBase::transpose() const
Definition at line 274 of file TriangularMatrix.h.
Friends And Related Function Documentation
| TriangularProduct<Mode,false,OtherDerived,OtherDerived::IsVectorAtCompileTime,MatrixType,false> operator* | ( | const MatrixBase< OtherDerived > & | lhs, |
| const TriangularView< _MatrixType, _Mode > & | rhs | ||
| ) | [friend] |
Efficient vector/matrix times triangular matrix product
Definition at line 292 of file TriangularMatrix.h.
Member Data Documentation
MatrixTypeNested Eigen::TriangularView< _MatrixType, _Mode >::m_matrix [protected] |
Definition at line 423 of file TriangularMatrix.h.
The documentation for this class was generated from the following files:
