Go to the source code of this file.
Classes | |
| struct | OBCameraParams |
| struct | OniCropping |
| struct | OniDeviceCallbacks |
| struct | OniDeviceInfo |
| struct | OniFrame |
| struct | OniRGB888Pixel |
| struct | OniSeek |
| struct | OniSensorInfo |
| struct | OniVersion |
| struct | OniVideoMode |
| struct | OniYUV422DoublePixel |
| struct | OniYUYVDoublePixel |
Macros | |
| #define | FALSE 0 |
| #define | ONI_MAX_SENSORS 10 |
| #define | ONI_MAX_STR 256 |
| #define | TRUE 1 |
Typedefs | |
| typedef struct OBCameraParams | OBCameraParams |
| typedef int | OniBool |
| typedef struct OniCallbackHandleImpl * | OniCallbackHandle |
| typedef uint16_t | OniDepthPixel |
| typedef struct _OniDevice * | OniDeviceHandle |
| typedef void(ONI_CALLBACK_TYPE * | OniDeviceInfoCallback) (const OniDeviceInfo *pInfo, void *pCookie) |
| typedef void(ONI_CALLBACK_TYPE * | OniDeviceStateCallback) (const OniDeviceInfo *pInfo, OniDeviceState deviceState, void *pCookie) |
| typedef void *(ONI_CALLBACK_TYPE * | OniFrameAllocBufferCallback) (int size, void *pCookie) |
| typedef void(ONI_CALLBACK_TYPE * | OniFrameFreeBufferCallback) (void *data, void *pCookie) |
| typedef void(ONI_CALLBACK_TYPE * | OniGeneralCallback) (void *pCookie) |
| typedef uint16_t | OniGrayscale16Pixel |
| typedef uint8_t | OniGrayscale8Pixel |
| typedef int | OniHardwareVersion |
| typedef uint16_t | OniIRPixel |
| typedef void(ONI_CALLBACK_TYPE * | OniNewFrameCallback) (OniStreamHandle stream, void *pCookie) |
| typedef struct _OniRecorder * | OniRecorderHandle |
| typedef struct _OniStream * | OniStreamHandle |
Macro Definition Documentation
◆ FALSE
| #define FALSE 0 |
Definition at line 34 of file OniCTypes.h.
◆ ONI_MAX_SENSORS
| #define ONI_MAX_SENSORS 10 |
Definition at line 38 of file OniCTypes.h.
◆ ONI_MAX_STR
| #define ONI_MAX_STR 256 |
Definition at line 37 of file OniCTypes.h.
◆ TRUE
| #define TRUE 1 |
Definition at line 31 of file OniCTypes.h.
Typedef Documentation
◆ OBCameraParams
| typedef struct OBCameraParams OBCameraParams |
◆ OniBool
| typedef int OniBool |
Basic types
Definition at line 28 of file OniCTypes.h.
◆ OniCallbackHandle
| typedef struct OniCallbackHandleImpl* OniCallbackHandle |
Definition at line 41 of file OniCTypes.h.
◆ OniDepthPixel
| typedef uint16_t OniDepthPixel |
Pixel type used to store depth images.
Definition at line 154 of file OniCTypes.h.
◆ OniDeviceHandle
| typedef struct _OniDevice* OniDeviceHandle |
Definition at line 97 of file OniCTypes.h.
◆ OniDeviceInfoCallback
| typedef void(ONI_CALLBACK_TYPE* OniDeviceInfoCallback) (const OniDeviceInfo *pInfo, void *pCookie) |
Definition at line 128 of file OniCTypes.h.
◆ OniDeviceStateCallback
| typedef void(ONI_CALLBACK_TYPE* OniDeviceStateCallback) (const OniDeviceInfo *pInfo, OniDeviceState deviceState, void *pCookie) |
Definition at line 129 of file OniCTypes.h.
◆ OniFrameAllocBufferCallback
| typedef void*(ONI_CALLBACK_TYPE* OniFrameAllocBufferCallback) (int size, void *pCookie) |
Definition at line 131 of file OniCTypes.h.
◆ OniFrameFreeBufferCallback
| typedef void(ONI_CALLBACK_TYPE* OniFrameFreeBufferCallback) (void *data, void *pCookie) |
Definition at line 132 of file OniCTypes.h.
◆ OniGeneralCallback
| typedef void(ONI_CALLBACK_TYPE* OniGeneralCallback) (void *pCookie) |
Definition at line 127 of file OniCTypes.h.
◆ OniGrayscale16Pixel
| typedef uint16_t OniGrayscale16Pixel |
Pixel type used to store 16-bit grayscale images
Definition at line 160 of file OniCTypes.h.
◆ OniGrayscale8Pixel
| typedef uint8_t OniGrayscale8Pixel |
Pixel type used to store 8-bit grayscale/bayer images
Definition at line 165 of file OniCTypes.h.
◆ OniHardwareVersion
| typedef int OniHardwareVersion |
Definition at line 56 of file OniCTypes.h.
◆ OniIRPixel
| typedef uint16_t OniIRPixel |
Definition at line 155 of file OniCTypes.h.
◆ OniNewFrameCallback
| typedef void(ONI_CALLBACK_TYPE* OniNewFrameCallback) (OniStreamHandle stream, void *pCookie) |
Definition at line 126 of file OniCTypes.h.
◆ OniRecorderHandle
| typedef struct _OniRecorder* OniRecorderHandle |
Definition at line 103 of file OniCTypes.h.
◆ OniStreamHandle
| typedef struct _OniStream* OniStreamHandle |
Definition at line 100 of file OniCTypes.h.
