#include <PropertyT.hh>
Public Types | |
| typedef field_t::StoredType | element_t |
| typedef property_t::StoredFieldType | field_t |
| typedef property_t::PtrType | property_ptr_t |
| typedef GeoProperty | property_t |
| typedef field_t::StoredType | value_type |
Public Member Functions | |
| void | clear (void) |
| Clear all elements and free memory. | |
| virtual oPropertyT< property_t > * | clone () const |
| Return a deep copy of self. | |
| const element_t * | data () const |
| virtual size_t | element_size () const |
| Size of one element in bytes or UnknownSize if not known. | |
| virtual size_t | n_elements () const |
| Number of elements in property. | |
| oPropertyT & | operator= (const oPropertyT &_rhs) |
| const element_t & | operator[] (size_t idx) const |
| element_t & | operator[] (size_t idx) |
| oPropertyT (const std::string &_name="<unknown>") | |
| oPropertyT (property_ptr_t _geo_prop, const std::string &_name="<unknown>") | |
| const property_ptr_t & | osg_ptr () const |
| property_ptr_t & | osg_ptr () |
| virtual void | push_back () |
| Extend the number of elements by one. | |
| virtual void | reserve (size_t _n) |
| Reserve memory for n elements. | |
| virtual void | resize (size_t _n) |
| Resize storage to hold n elements. | |
| virtual size_t | restore (std::istream &_istr, bool _swap) |
| virtual void | set_persistent (bool _yn) |
| virtual size_t | store (std::ostream &_ostr, bool _swap) const |
| Store self as one binary block. | |
| virtual void | swap (size_t _i0, size_t _i1) |
| Let two elements swap their storage place. | |
| virtual | ~oPropertyT () |
Protected Attributes | |
| property_ptr_t | data_ |
Private Member Functions | |
| oPropertyT (const oPropertyT &) | |
| void | osg_init_check (void) |
Property adaptor for OpenSG GeoProperties
This class bridges the interfaces of OpenMesh properties and OpenSG GeoProperties. The PropertyKernelT uses these adaptors to add all necessary property functions to the kernel, while the AttribKernelT extends the kernel with the standard properites. Finally the ArrayKernelT completes the kernel build with a specialized version of the garbage collections since the GeoIndices require special handling.
Definition at line 85 of file PropertyT.hh.
| typedef field_t::StoredType OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::element_t |
Definition at line 94 of file PropertyT.hh.
| typedef property_t::StoredFieldType OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::field_t |
Definition at line 93 of file PropertyT.hh.
| typedef property_t::PtrType OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::property_ptr_t |
Reimplemented in OpenMesh::Kernel_OSG::FP::GeoIndicesUI32< IsTriMesh >.
Definition at line 91 of file PropertyT.hh.
| typedef GeoProperty OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::property_t |
Definition at line 90 of file PropertyT.hh.
| typedef field_t::StoredType OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::value_type |
Definition at line 95 of file PropertyT.hh.
| OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::oPropertyT | ( | property_ptr_t | _geo_prop, | |
| const std::string & | _name = "<unknown>" | |||
| ) | [inline] |
Definition at line 100 of file PropertyT.hh.
| OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::oPropertyT | ( | const std::string & | _name = "<unknown>" |
) | [inline] |
Definition at line 108 of file PropertyT.hh.
| virtual OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::~oPropertyT | ( | ) | [inline, virtual] |
Definition at line 119 of file PropertyT.hh.
| OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::oPropertyT | ( | const oPropertyT< GeoProperty > & | ) | [private] |
| void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::clear | ( | void | ) | [inline, virtual] |
Clear all elements and free memory.
Implements OpenMesh::BaseProperty.
Definition at line 179 of file PropertyT.hh.
| virtual oPropertyT<property_t>* OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::clone | ( | ) | const [inline, virtual] |
Return a deep copy of self.
Implements OpenMesh::BaseProperty.
Definition at line 142 of file PropertyT.hh.
| const element_t* OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::data | ( | ) | const [inline] |
Definition at line 191 of file PropertyT.hh.
| virtual size_t OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::element_size | ( | ) | const [inline, virtual] |
Size of one element in bytes or UnknownSize if not known.
Implements OpenMesh::BaseProperty.
Definition at line 167 of file PropertyT.hh.
| virtual size_t OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::n_elements | ( | ) | const [inline, virtual] |
Number of elements in property.
Implements OpenMesh::BaseProperty.
Definition at line 164 of file PropertyT.hh.
| oPropertyT& OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::operator= | ( | const oPropertyT< GeoProperty > & | _rhs | ) | [inline] |
Definition at line 124 of file PropertyT.hh.
| const element_t& OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::operator[] | ( | size_t | idx | ) | const [inline] |
Definition at line 197 of file PropertyT.hh.
| element_t& OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::operator[] | ( | size_t | idx | ) | [inline] |
Definition at line 194 of file PropertyT.hh.
| void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::osg_init_check | ( | void | ) | [inline, private] |
Definition at line 208 of file PropertyT.hh.
| const property_ptr_t& OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::osg_ptr | ( | ) | const [inline] |
Definition at line 187 of file PropertyT.hh.
| property_ptr_t& OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::osg_ptr | ( | ) | [inline] |
Definition at line 184 of file PropertyT.hh.
| virtual void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::push_back | ( | ) | [inline, virtual] |
Extend the number of elements by one.
Implements OpenMesh::BaseProperty.
Definition at line 138 of file PropertyT.hh.
| virtual void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::reserve | ( | size_t | _n | ) | [inline, virtual] |
Reserve memory for n elements.
Implements OpenMesh::BaseProperty.
Reimplemented in OpenMesh::Kernel_OSG::FP::GeoIndicesUI32< IsTriMesh >.
Definition at line 136 of file PropertyT.hh.
| virtual void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::resize | ( | size_t | _n | ) | [inline, virtual] |
Resize storage to hold n elements.
Implements OpenMesh::BaseProperty.
Reimplemented in OpenMesh::Kernel_OSG::FP::GeoIndicesUI32< IsTriMesh >.
Definition at line 137 of file PropertyT.hh.
| virtual size_t OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::restore | ( | std::istream & | _istr, | |
| bool | _swap | |||
| ) | [inline, virtual] |
Restore self from a binary block. Uses reserve() to set the size of self before restoring.
Implements OpenMesh::BaseProperty.
Definition at line 173 of file PropertyT.hh.
| virtual void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::set_persistent | ( | bool | _yn | ) | [inline, virtual] |
Enable or disable persistency. Self must be a named property to enable persistency.
Implements OpenMesh::BaseProperty.
Definition at line 159 of file PropertyT.hh.
| virtual size_t OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::store | ( | std::ostream & | _ostr, | |
| bool | _swap | |||
| ) | const [inline, virtual] |
Store self as one binary block.
Implements OpenMesh::BaseProperty.
Definition at line 170 of file PropertyT.hh.
| virtual void OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::swap | ( | size_t | _i0, | |
| size_t | _i1 | |||
| ) | [inline, virtual] |
Let two elements swap their storage place.
Implements OpenMesh::BaseProperty.
Reimplemented in OpenMesh::Kernel_OSG::FP::GeoIndicesUI32< IsTriMesh >.
Definition at line 139 of file PropertyT.hh.
property_ptr_t OpenMesh::Kernel_OSG::oPropertyT< GeoProperty >::data_ [protected] |
Definition at line 203 of file PropertyT.hh.
