ring_buffer.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	ring_buf_t

Functions
int	ringBufClear (ring_buf_t *rbuf)
	Clear the entire buffer. More...
int	ringBufEmpty (const ring_buf_t *rbuf)
	This function returns 1 if the buffer is empty, 0 if not empty. More...
int	ringBufFind (const ring_buf_t *rbuf, const unsigned char *str, int len)
	This function finds the index of the first matching string in the ring buffer. Returns -1 if not found. More...
int	ringBufFree (const ring_buf_t *rbuf)
	This function returns the number of bytes free in UART Rx buffer. Important: Buffer size is one less than init buffer size so pointers don't wrap. More...
void	ringBufInit (ring_buf_t *rbuf, unsigned char *buf, int bufSize, int wordSize)
	Initialize ring buffer pointers. More...
int	ringBufPeek (const ring_buf_t *rbuf, unsigned char *buf, int len, int offset)
	This function reads data from the ring buffer without removing any data. Same as ringBufPop without moving pointers. More...
int	ringBufRead (ring_buf_t *rbuf, unsigned char *buf, int len)
	This function reads data from the ring buffer. More...
int	ringBufReadToChar (ring_buf_t *rbuf, unsigned char *buf, int len, unsigned char character)
	This function returns everything up to and including the first occurrence of a character. If the character is not found, then nothing (zero) is returned. More...
int	ringBufReadToChar2 (ring_buf_t *rbuf, unsigned char *buf, int len, unsigned char character1, unsigned char character2)
	This function returns everything up to and including the first occurrence of a character. If the character is not found, then nothing (zero) is returned. More...
int	ringBufRemove (ring_buf_t *rbuf, int len)
	This function removes data from the ring buffer. More...
int	ringBufUsed (const ring_buf_t *rbuf)
	This function returns the number of bytes currently in ring buffer. More...
int	ringBufWrite (ring_buf_t *rbuf, unsigned char *buf, int numBytes)
	This function writes data to the ring buffer. More...

Function Documentation

ringBufClear()

int ringBufClear

(

ring_buf_t *

rbuf

)

Clear the entire buffer.

Returns

Number of bytes removed.

Definition at line 467 of file ring_buffer.c.

ringBufEmpty()

int ringBufEmpty

(

const ring_buf_t *

rbuf

)

This function returns 1 if the buffer is empty, 0 if not empty.

Definition at line 481 of file ring_buffer.c.

ringBufFind()

int ringBufFind	(	const ring_buf_t *	rbuf,
		const unsigned char *	str,
		int	len
	)

This function finds the index of the first matching string in the ring buffer. Returns -1 if not found.

Parameters

rbuf	Ring buffer struct pointer.
len	Length of data to attempt reading.
str	Character string to search for.

Returns

Index of the first matching string. -1 if not found.

Definition at line 387 of file ring_buffer.c.

ringBufFree()

int ringBufFree

(

const ring_buf_t *

rbuf

)

This function returns the number of bytes free in UART Rx buffer. Important: Buffer size is one less than init buffer size so pointers don't wrap.

Definition at line 61 of file ring_buffer.c.

ringBufInit()

void ringBufInit	(	ring_buf_t *	rbuf,
		unsigned char *	buf,
		int	bufSize,
		int	wordSize
	)

Initialize ring buffer pointers.

Definition at line 29 of file ring_buffer.c.

ringBufPeek()

int ringBufPeek	(	const ring_buf_t *	rbuf,
		unsigned char *	buf,
		int	len,
		int	offset
	)

This function reads data from the ring buffer without removing any data. Same as ringBufPop without moving pointers.

Parameters

rbuf	Ring buffer struct pointer.
buf	Buffer to copy data to.
len	Length of data to attempt reading.

Returns

Actual number of bytes read.

Definition at line 188 of file ring_buffer.c.

ringBufRead()

int ringBufRead	(	ring_buf_t *	rbuf,
		unsigned char *	buf,
		int	len
	)

This function reads data from the ring buffer.

Parameters

rbuf	Ring buffer struct pointer.
buf	Buffer to copy data to.
len	Length of data to attempt reading.

Returns

Actual number of bytes read.

Definition at line 136 of file ring_buffer.c.

ringBufReadToChar()

int ringBufReadToChar	(	ring_buf_t *	rbuf,
		unsigned char *	buf,
		int	len,
		unsigned char	character
	)

This function returns everything up to and including the first occurrence of a character. If the character is not found, then nothing (zero) is returned.

Parameters

rbuf	Ring buffer struct pointer.
buf	Buffer to copy data to.
len	Length of data to attempt reading.
character	Value to search for.

Returns

Number of bytes read.

Definition at line 288 of file ring_buffer.c.

ringBufReadToChar2()

int ringBufReadToChar2	(	ring_buf_t *	rbuf,
		unsigned char *	buf,
		int	len,
		unsigned char	character1,
		unsigned char	character2
	)

This function returns everything up to and including the first occurrence of a character. If the character is not found, then nothing (zero) is returned.

Parameters

rbuf	Ring buffer struct pointer.
buf	Buffer to copy data to.
len	Length of data to attempt reading.
character1	Value to search for.
character2	Value to search for.

Returns

Number of bytes read.

Definition at line 306 of file ring_buffer.c.

ringBufRemove()

int ringBufRemove	(	ring_buf_t *	rbuf,
		int	len
	)

This function removes data from the ring buffer.

Parameters

rbuf	Ring buffer struct pointer.
len	Number of bytes to remove.

Returns

Actual number of bytes removed.

Definition at line 432 of file ring_buffer.c.

ringBufUsed()

int ringBufUsed

(

const ring_buf_t *

rbuf

)

This function returns the number of bytes currently in ring buffer.

Definition at line 43 of file ring_buffer.c.

ringBufWrite()

int ringBufWrite	(	ring_buf_t *	rb,
		unsigned char *	buf,
		int	numBytes
	)

This function writes data to the ring buffer.

Parameters

rbuf	Ring buffer struct pointer.
buf	Buffer to copy data from.
len	Length of data to copy.

Returns

0 on success, 1 on overflow.

Definition at line 76 of file ring_buffer.c.
