FatFS configurations. More...
Go to the source code of this file.
Macros | |
| #define | _CODE_PAGE 850 |
| #define | _FFCONF 6502 /* Revision ID */ |
| #define | _FS_MINIMIZE 0 /* 0 to 3 */ |
| #define | _FS_READONLY 0 /* 0:Read/Write or 1:Read only */ |
| #define | _FS_REENTRANT 0 /* 0:Disable or 1:Enable */ |
| #define | _FS_RPATH 0 /* 0 to 2 */ |
| #define | _FS_SHARE 0 /* 0:Disable or >=1:Enable */ |
| #define | _FS_TIMEOUT 1000 /* Timeout period in unit of time ticks */ |
| #define | _FS_TINY 1 /* 0:Normal or 1:Tiny */ |
| #define | _LFN_UNICODE 0 /* 0:ANSI/OEM or 1:Unicode */ |
| #define | _MAX_LFN 255 /* Maximum LFN length to handle (12 to 255) */ |
| #define | _MAX_SS 512 /* 512, 1024, 2048 or 4096 */ |
| #define | _MULTI_PARTITION 0 /* 0:Single partition, 1/2:Enable multiple partition */ |
| #define | _SYNC_t HANDLE /* O/S dependent type of sync object. e.g. HANDLE, OS_EVENT*, ID and etc.. */ |
| #define | _USE_ERASE 0 /* 0:Disable or 1:Enable */ |
| #define | _USE_FASTSEEK 0 /* 0:Disable or 1:Enable */ |
| #define | _USE_FORWARD 0 /* 0:Disable or 1:Enable */ |
| #define | _USE_LFN 2 /* 0 to 3 */ |
| #define | _USE_MKFS 1 /* 0:Disable or 1:Enable */ |
| #define | _USE_STRFUNC 1 /* 0:Disable or 1-2:Enable */ |
| #define | _VOLUMES 8 |
| #define | _WORD_ACCESS 0 /* 0 or 1 */ |
Detailed Description
FatFS configurations.
Copyright (c) 2014-2018 Microchip Technology Inc. and its subsidiaries.
Definition in file conf_fatfs.h.
Macro Definition Documentation
◆ _CODE_PAGE
| #define _CODE_PAGE 850 |
Definition at line 96 of file conf_fatfs.h.
◆ _FFCONF
| #define _FFCONF 6502 /* Revision ID */ |
Definition at line 47 of file conf_fatfs.h.
◆ _FS_MINIMIZE
| #define _FS_MINIMIZE 0 /* 0 to 3 */ |
Definition at line 66 of file conf_fatfs.h.
◆ _FS_READONLY
Definition at line 60 of file conf_fatfs.h.
◆ _FS_REENTRANT
| #define _FS_REENTRANT 0 /* 0:Disable or 1:Enable */ |
Definition at line 208 of file conf_fatfs.h.
◆ _FS_RPATH
| #define _FS_RPATH 0 /* 0 to 2 */ |
Definition at line 148 of file conf_fatfs.h.
◆ _FS_SHARE
| #define _FS_SHARE 0 /* 0:Disable or >=1:Enable */ |
Definition at line 220 of file conf_fatfs.h.
◆ _FS_TIMEOUT
| #define _FS_TIMEOUT 1000 /* Timeout period in unit of time ticks */ |
Definition at line 209 of file conf_fatfs.h.
◆ _FS_TINY
| #define _FS_TINY 1 /* 0:Normal or 1:Tiny */ |
Definition at line 54 of file conf_fatfs.h.
◆ _LFN_UNICODE
| #define _LFN_UNICODE 0 /* 0:ANSI/OEM or 1:Unicode */ |
Definition at line 143 of file conf_fatfs.h.
◆ _MAX_LFN
| #define _MAX_LFN 255 /* Maximum LFN length to handle (12 to 255) */ |
Definition at line 129 of file conf_fatfs.h.
◆ _MAX_SS
| #define _MAX_SS 512 /* 512, 1024, 2048 or 4096 */ |
Definition at line 167 of file conf_fatfs.h.
◆ _MULTI_PARTITION
| #define _MULTI_PARTITION 0 /* 0:Single partition, 1/2:Enable multiple partition */ |
Definition at line 175 of file conf_fatfs.h.
◆ _SYNC_t
| #define _SYNC_t HANDLE /* O/S dependent type of sync object. e.g. HANDLE, OS_EVENT*, ID and etc.. */ |
Definition at line 210 of file conf_fatfs.h.
◆ _USE_ERASE
| #define _USE_ERASE 0 /* 0:Disable or 1:Enable */ |
Definition at line 181 of file conf_fatfs.h.
◆ _USE_FASTSEEK
| #define _USE_FASTSEEK 0 /* 0:Disable or 1:Enable */ |
Definition at line 88 of file conf_fatfs.h.
◆ _USE_FORWARD
| #define _USE_FORWARD 0 /* 0:Disable or 1:Enable */ |
Definition at line 84 of file conf_fatfs.h.
◆ _USE_LFN
| #define _USE_LFN 2 /* 0 to 3 */ |
Definition at line 128 of file conf_fatfs.h.
◆ _USE_MKFS
| #define _USE_MKFS 1 /* 0:Disable or 1:Enable */ |
Definition at line 80 of file conf_fatfs.h.
◆ _USE_STRFUNC
| #define _USE_STRFUNC 1 /* 0:Disable or 1-2:Enable */ |
Definition at line 76 of file conf_fatfs.h.
◆ _VOLUMES
| #define _VOLUMES 8 |
Definition at line 163 of file conf_fatfs.h.
◆ _WORD_ACCESS
| #define _WORD_ACCESS 0 /* 0 or 1 */ |
Definition at line 191 of file conf_fatfs.h.
