Go to the source code of this file.
Classes | |
| class | YSpiPort |
Macros | |
| #define | _Y_SHITFTSAMPLING_ENUM |
| #define | _Y_SSPOLARITY_ENUM |
| #define | _Y_VOLTAGELEVEL_ENUM |
| #define | Y_COMMAND_INVALID (YAPI_INVALID_STRING) |
| #define | Y_CURRENTJOB_INVALID (YAPI_INVALID_STRING) |
| #define | Y_ERRCOUNT_INVALID (YAPI_INVALID_UINT) |
| #define | Y_LASTMSG_INVALID (YAPI_INVALID_STRING) |
| #define | Y_PROTOCOL_INVALID (YAPI_INVALID_STRING) |
| #define | Y_RXCOUNT_INVALID (YAPI_INVALID_UINT) |
| #define | Y_RXMSGCOUNT_INVALID (YAPI_INVALID_UINT) |
| #define | Y_SPIMODE_INVALID (YAPI_INVALID_STRING) |
| #define | Y_STARTUPJOB_INVALID (YAPI_INVALID_STRING) |
| #define | Y_TXCOUNT_INVALID (YAPI_INVALID_UINT) |
| #define | Y_TXMSGCOUNT_INVALID (YAPI_INVALID_UINT) |
Typedefs | |
| typedef void(* | YSpiPortValueCallback) (YSpiPort *func, const string &functionValue) |
Enumerations | |
| enum | Y_SHITFTSAMPLING_enum { Y_SHITFTSAMPLING_OFF = 0, Y_SHITFTSAMPLING_ON = 1, Y_SHITFTSAMPLING_INVALID = -1 } |
| enum | Y_SSPOLARITY_enum { Y_SSPOLARITY_ACTIVE_LOW = 0, Y_SSPOLARITY_ACTIVE_HIGH = 1, Y_SSPOLARITY_INVALID = -1 } |
| enum | Y_VOLTAGELEVEL_enum { Y_VOLTAGELEVEL_OFF = 0, Y_VOLTAGELEVEL_TTL3V = 1, Y_VOLTAGELEVEL_TTL3VR = 2, Y_VOLTAGELEVEL_TTL5V = 3, Y_VOLTAGELEVEL_TTL5VR = 4, Y_VOLTAGELEVEL_RS232 = 5, Y_VOLTAGELEVEL_RS485 = 6, Y_VOLTAGELEVEL_INVALID = -1, Y_VOLTAGELEVEL_OFF = 0, Y_VOLTAGELEVEL_TTL3V = 1, Y_VOLTAGELEVEL_TTL3VR = 2, Y_VOLTAGELEVEL_TTL5V = 3, Y_VOLTAGELEVEL_TTL5VR = 4, Y_VOLTAGELEVEL_RS232 = 5, Y_VOLTAGELEVEL_RS485 = 6, Y_VOLTAGELEVEL_INVALID = -1 } |
Functions | |
| YSpiPort * | yFindSpiPort (const string &func) |
| YSpiPort * | yFirstSpiPort (void) |
Macro Definition Documentation
| #define _Y_SHITFTSAMPLING_ENUM |
Definition at line 77 of file yocto_spiport.h.
| #define _Y_SSPOLARITY_ENUM |
Definition at line 69 of file yocto_spiport.h.
| #define _Y_VOLTAGELEVEL_ENUM |
Definition at line 56 of file yocto_spiport.h.
| #define Y_COMMAND_INVALID (YAPI_INVALID_STRING) |
Definition at line 92 of file yocto_spiport.h.
| #define Y_CURRENTJOB_INVALID (YAPI_INVALID_STRING) |
Definition at line 90 of file yocto_spiport.h.
| #define Y_ERRCOUNT_INVALID (YAPI_INVALID_UINT) |
Definition at line 86 of file yocto_spiport.h.
| #define Y_LASTMSG_INVALID (YAPI_INVALID_STRING) |
Definition at line 89 of file yocto_spiport.h.
| #define Y_PROTOCOL_INVALID (YAPI_INVALID_STRING) |
Definition at line 93 of file yocto_spiport.h.
| #define Y_RXCOUNT_INVALID (YAPI_INVALID_UINT) |
Definition at line 84 of file yocto_spiport.h.
| #define Y_RXMSGCOUNT_INVALID (YAPI_INVALID_UINT) |
Definition at line 87 of file yocto_spiport.h.
| #define Y_SPIMODE_INVALID (YAPI_INVALID_STRING) |
Definition at line 94 of file yocto_spiport.h.
| #define Y_STARTUPJOB_INVALID (YAPI_INVALID_STRING) |
Definition at line 91 of file yocto_spiport.h.
| #define Y_TXCOUNT_INVALID (YAPI_INVALID_UINT) |
Definition at line 85 of file yocto_spiport.h.
| #define Y_TXMSGCOUNT_INVALID (YAPI_INVALID_UINT) |
Definition at line 88 of file yocto_spiport.h.
Typedef Documentation
| typedef void(* YSpiPortValueCallback) (YSpiPort *func, const string &functionValue) |
Definition at line 54 of file yocto_spiport.h.
Enumeration Type Documentation
| Enumerator | |
|---|---|
| Y_SHITFTSAMPLING_OFF | |
| Y_SHITFTSAMPLING_ON | |
| Y_SHITFTSAMPLING_INVALID | |
Definition at line 78 of file yocto_spiport.h.
| enum Y_SSPOLARITY_enum |
| Enumerator | |
|---|---|
| Y_SSPOLARITY_ACTIVE_LOW | |
| Y_SSPOLARITY_ACTIVE_HIGH | |
| Y_SSPOLARITY_INVALID | |
Definition at line 70 of file yocto_spiport.h.
| enum Y_VOLTAGELEVEL_enum |
Definition at line 57 of file yocto_spiport.h.
Function Documentation
|
inline |
Retrieves a SPI port for a given identifier. The identifier can be specified using several formats:
- FunctionLogicalName
- ModuleSerialNumber.FunctionIdentifier
- ModuleSerialNumber.FunctionLogicalName
- ModuleLogicalName.FunctionIdentifier
- ModuleLogicalName.FunctionLogicalName
This function does not require that the SPI port is online at the time it is invoked. The returned object is nevertheless valid. Use the method YSpiPort.isOnline() to test if the SPI port is indeed online at a given time. In case of ambiguity when looking for a SPI port by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.
If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.
- Parameters
-
func : a string that uniquely characterizes the SPI port
- Returns
- a YSpiPort object allowing you to drive the SPI port.
Definition at line 824 of file yocto_spiport.h.
|
inline |
Starts the enumeration of SPI ports currently accessible. Use the method YSpiPort.nextSpiPort() to iterate on next SPI ports.
- Returns
- a pointer to a YSpiPort object, corresponding to the first SPI port currently online, or a NULL pointer if there are none.
Definition at line 835 of file yocto_spiport.h.
