Go to the source code of this file.
Classes | |
| class | YPwmInput |
Macros | |
| #define | _Y_PWMREPORTMODE_ENUM |
| #define | Y_DEBOUNCEPERIOD_INVALID (YAPI_INVALID_UINT) |
| #define | Y_DUTYCYCLE_INVALID (YAPI_INVALID_DOUBLE) |
| #define | Y_FREQUENCY_INVALID (YAPI_INVALID_DOUBLE) |
| #define | Y_PERIOD_INVALID (YAPI_INVALID_DOUBLE) |
| #define | Y_PULSECOUNTER_INVALID (YAPI_INVALID_LONG) |
| #define | Y_PULSEDURATION_INVALID (YAPI_INVALID_DOUBLE) |
| #define | Y_PULSETIMER_INVALID (YAPI_INVALID_LONG) |
Typedefs | |
| typedef void(* | YPwmInputTimedReportCallback) (YPwmInput *func, YMeasure measure) |
| typedef void(* | YPwmInputValueCallback) (YPwmInput *func, const string &functionValue) |
Enumerations | |
| enum | Y_PWMREPORTMODE_enum { Y_PWMREPORTMODE_PWM_DUTYCYCLE = 0, Y_PWMREPORTMODE_PWM_FREQUENCY = 1, Y_PWMREPORTMODE_PWM_PULSEDURATION = 2, Y_PWMREPORTMODE_PWM_EDGECOUNT = 3, Y_PWMREPORTMODE_PWM_PULSECOUNT = 4, Y_PWMREPORTMODE_PWM_CPS = 5, Y_PWMREPORTMODE_PWM_CPM = 6, Y_PWMREPORTMODE_PWM_STATE = 7, Y_PWMREPORTMODE_INVALID = -1 } |
Functions | |
| YPwmInput * | yFindPwmInput (const string &func) |
| YPwmInput * | yFirstPwmInput (void) |
Macro Definition Documentation
| #define _Y_PWMREPORTMODE_ENUM |
Definition at line 58 of file yocto_pwminput.h.
| #define Y_DEBOUNCEPERIOD_INVALID (YAPI_INVALID_UINT) |
Definition at line 77 of file yocto_pwminput.h.
| #define Y_DUTYCYCLE_INVALID (YAPI_INVALID_DOUBLE) |
Definition at line 71 of file yocto_pwminput.h.
| #define Y_FREQUENCY_INVALID (YAPI_INVALID_DOUBLE) |
Definition at line 73 of file yocto_pwminput.h.
| #define Y_PERIOD_INVALID (YAPI_INVALID_DOUBLE) |
Definition at line 74 of file yocto_pwminput.h.
| #define Y_PULSECOUNTER_INVALID (YAPI_INVALID_LONG) |
Definition at line 75 of file yocto_pwminput.h.
| #define Y_PULSEDURATION_INVALID (YAPI_INVALID_DOUBLE) |
Definition at line 72 of file yocto_pwminput.h.
| #define Y_PULSETIMER_INVALID (YAPI_INVALID_LONG) |
Definition at line 76 of file yocto_pwminput.h.
Typedef Documentation
Definition at line 56 of file yocto_pwminput.h.
| typedef void(* YPwmInputValueCallback) (YPwmInput *func, const string &functionValue) |
Definition at line 54 of file yocto_pwminput.h.
Enumeration Type Documentation
| enum Y_PWMREPORTMODE_enum |
Definition at line 59 of file yocto_pwminput.h.
Function Documentation
|
inline |
Retrieves a PWM input for a given identifier. The identifier can be specified using several formats:
- FunctionLogicalName
- ModuleSerialNumber.FunctionIdentifier
- ModuleSerialNumber.FunctionLogicalName
- ModuleLogicalName.FunctionIdentifier
- ModuleLogicalName.FunctionLogicalName
This function does not require that the PWM input is online at the time it is invoked. The returned object is nevertheless valid. Use the method YPwmInput.isOnline() to test if the PWM input is indeed online at a given time. In case of ambiguity when looking for a PWM input by logical name, no error is notified: the first instance found is returned. The search is performed first by hardware name, then by logical name.
If a call to this object's is_online() method returns FALSE although you are certain that the matching device is plugged, make sure that you did call registerHub() at application initialization time.
- Parameters
-
func : a string that uniquely characterizes the PWM input
- Returns
- a YPwmInput object allowing you to drive the PWM input.
Definition at line 413 of file yocto_pwminput.h.
|
inline |
Starts the enumeration of PWM inputs currently accessible. Use the method YPwmInput.nextPwmInput() to iterate on next PWM inputs.
- Returns
- a pointer to a YPwmInput object, corresponding to the first PWM input currently online, or a NULL pointer if there are none.
Definition at line 424 of file yocto_pwminput.h.
