Mercury API - Reader parameter interface. More...
Go to the source code of this file.
Detailed Description
Define Documentation
| #define TMR_PARAMWORDS ((1 + TMR_PARAM_MAX +31) / 32) |
Definition at line 216 of file tmr_params.h.
Typedef Documentation
Parameter keys for TMR_paramSet() and TMR_paramGet(). Each parameter is listed with its associated string name and the parameter type. A pointer to that type is passed to TMR_paramGet() (for example, "TMR_String *" for /reader/version/model).
Enumeration Type Documentation
| enum TMR_Param |
Parameter keys for TMR_paramSet() and TMR_paramGet(). Each parameter is listed with its associated string name and the parameter type. A pointer to that type is passed to TMR_paramGet() (for example, "TMR_String *" for /reader/version/model).
- Enumerator:
TMR_PARAM_NONE No such parameter - used as a return value from TMR_paramID().
TMR_PARAM_MIN TMR_PARAM_BAUDRATE "/reader/baudRate", uint32_t
TMR_PARAM_PROBEBAUDRATES "/reader/probeBaudRates", TMR_uint32List
TMR_PARAM_COMMANDTIMEOUT "/reader/commandTimeout", uint32_t
TMR_PARAM_TRANSPORTTIMEOUT "/reader/transportTimeout", uint32_t
TMR_PARAM_POWERMODE "/reader/powerMode", TMR_SR_PowerMode
TMR_PARAM_USERMODE "/reader/userMode", TMR_SR_UserMode
TMR_PARAM_ANTENNA_CHECKPORT "/reader/antenna/checkPort", bool
TMR_PARAM_ANTENNA_PORTLIST "/reader/antenna/portList", TMR_uint8List
TMR_PARAM_ANTENNA_CONNECTEDPORTLIST "/reader/antenna/connectedPortList", TMR_uint8List
TMR_PARAM_ANTENNA_PORTSWITCHGPOS "/reader/antenna/portSwitchGpos", TMR_uint8List
TMR_PARAM_ANTENNA_SETTLINGTIMELIST "/reader/antenna/settlingTimeList", TMR_PortValueList
TMR_PARAM_ANTENNA_RETURNLOSS "reader/antenna/returnLoss", TMR_PortValueList
TMR_PARAM_ANTENNA_TXRXMAP "/reader/antenna/txRxMap", TMR_AntennaMapList
TMR_PARAM_GPIO_INPUTLIST "/reader/gpio/inputList", TMR_uint8List
TMR_PARAM_GPIO_OUTPUTLIST "/reader/gpio/outputList", TMR_uint8List
TMR_PARAM_GEN2_ACCESSPASSWORD "/reader/gen2/accessPassword", TMR_GEN2_Password
TMR_PARAM_GEN2_Q "/reader/gen2/q", TMR_GEN2_Q
TMR_PARAM_GEN2_TAGENCODING "/reader/gen2/tagEncoding", TMR_GEN2_TagEncoding
TMR_PARAM_GEN2_SESSION "/reader/gen2/session", TMR_GEN2_Session
TMR_PARAM_GEN2_TARGET "/reader/gen2/target", TMR_GEN2_Target
TMR_PARAM_GEN2_BLF "/reader/gen2/BLF", TMR_Gen2_LinkFrequency
TMR_PARAM_GEN2_TARI "/reader/gen2/tari", TMR_Gen2_Tari
TMR_PARAM_GEN2_WRITEMODE "/reader/gen2/writeMode", TMR_Gen2_WriteMode
TMR_PARAM_GEN2_BAP "/reader/gen2/bap", TMR_Gen2_Bap
TMR_PARAM_GEN2_PROTOCOLEXTENSION "/reader/gen2/protocolExtension", TMR_PARAM_GEN2_PROTOCOLEXTENSION
TMR_PARAM_ISO180006B_BLF "/reader/iso180006b/BLF", TMR_ISO180006B_LinkFrequency
TMR_PARAM_ISO180006B_MODULATION_DEPTH "/reader/iso180006b/modulationDepth", TMR_ISO180006B_ModulationDepth
TMR_PARAM_ISO180006B_DELIMITER "/reader/iso180006b/delimiter", TMR_PARAM_ISO18000_6B_DELIMITER
TMR_PARAM_READ_ASYNCOFFTIME "/reader/read/asyncOffTime", uint32_t
TMR_PARAM_READ_ASYNCONTIME "/reader/read/asyncOnTime", uint32_t
TMR_PARAM_READ_PLAN "/reader/read/plan", TMR_ReadPlan
TMR_PARAM_RADIO_ENABLEPOWERSAVE "/reader/radio/enablePowerSave, bool
TMR_PARAM_RADIO_POWERMAX "/reader/radio/powerMax", int16_t
TMR_PARAM_RADIO_POWERMIN "/reader/radio/powerMin", int16_t
TMR_PARAM_RADIO_PORTREADPOWERLIST "/reader/radio/portReadPowerList", TMR_PortValueList
TMR_PARAM_RADIO_PORTWRITEPOWERLIST "/reader/radio/portWritePowerList", TMR_PortValueList
TMR_PARAM_RADIO_READPOWER "/reader/radio/readPower", int32_t
TMR_PARAM_RADIO_WRITEPOWER "/reader/radio/writePower", int32_t
TMR_PARAM_RADIO_TEMPERATURE "/reader/radio/temperature", int8_t
TMR_PARAM_TAGREADDATA_RECORDHIGHESTRSSI "/reader/tagReadData/recordHighestRssi", bool
TMR_PARAM_TAGREADDATA_REPORTRSSIINDBM "/reader/tagReadData/reportRssiInDbm", bool
TMR_PARAM_TAGREADDATA_UNIQUEBYANTENNA "/reader/tagReadData/uniqueByAntenna", bool
TMR_PARAM_TAGREADDATA_UNIQUEBYDATA "/reader/tagReadData/uniqueByData", bool
TMR_PARAM_TAGOP_ANTENNA "/reader/tagop/antenna", uint8_t
TMR_PARAM_TAGOP_PROTOCOL "/reader/tagop/protocol", TMR_Protocol
TMR_PARAM_VERSION_HARDWARE "/reader/version/hardware", TMR_String
TMR_PARAM_VERSION_SERIAL "/reader/version/serial", TMR_String
TMR_PARAM_VERSION_MODEL "/reader/version/model", TMR_String
TMR_PARAM_VERSION_SOFTWARE "/reader/version/software", TMR_String
TMR_PARAM_VERSION_SUPPORTEDPROTOCOLS "/reader/version/supportedProtocols", TMR_TagProtocolList
TMR_PARAM_REGION_HOPTABLE "/reader/region/hopTable", TMR_uint32List
TMR_PARAM_REGION_HOPTIME "/reader/region/hopTime", uint32_t
TMR_PARAM_REGION_ID "/reader/region/id", TMR_Region
TMR_PARAM_REGION_SUPPORTEDREGIONS "/reader/region/supportedRegions", TMR_RegionList
TMR_PARAM_REGION_LBT_ENABLE "/reader/region/lbt/enable", bool
TMR_PARAM_LICENSE_KEY "/reader/licenseKey", TMR_uint8List
TMR_PARAM_USER_CONFIG "/reader/userConfig", TMR_UserConfigOption
TMR_PARAM_RADIO_ENABLESJC "/reader/radio/enableSJC", bool
TMR_PARAM_EXTENDEDEPC "/reader/extendedEpc", bool
TMR_PARAM_READER_STATISTICS "/reader/statistics", TMR_SR_ReaderStatistics
TMR_PARAM_READER_STATS "/reader/stats", TMR_
TMR_PARAM_URI "/reader/uri", TMR_String
TMR_PARAM_PRODUCT_GROUP_ID "/reader/version/productGroupID", uint16_t
TMR_PARAM_PRODUCT_GROUP "/reader/version/productGroup", TMR_String
TMR_PARAM_PRODUCT_ID "/reader/version/productID", uint16_t
TMR_PARAM_TAGREADATA_TAGOPSUCCESSCOUNT "/reader/tagReadData/tagopSuccesses", uint16_t
TMR_PARAM_TAGREADATA_TAGOPFAILURECOUNT "/reader/tagReadData/tagopFailures", uint16_t
TMR_PARAM_STATUS_ENABLE_ANTENNAREPORT "/reader/status/antennaEnable", bool
TMR_PARAM_STATUS_ENABLE_FREQUENCYREPORT "/reader/status/frequencyEnable", bool
TMR_PARAM_STATUS_ENABLE_TEMPERATUREREPORT "/reader/status/temperatureEnable", bool
TMR_PARAM_TAGREADDATA_ENABLEREADFILTER "/reader/tagReadData/enableReadFilter", bool
TMR_PARAM_TAGREADDATA_READFILTERTIMEOUT "/reader/tagReadData/readFilterTimeout", int32_t
TMR_PARAM_TAGREADDATA_UNIQUEBYPROTOCOL "/reader/tagReadData/uniqueByProtocol", bool
TMR_PARAM_READER_DESCRIPTION "/reader/description", TMR_String
TMR_PARAM_READER_HOSTNAME "reader/hostname", TMR_String
TMR_PARAM_CURRENTTIME "/reader/currentTime", struct tm
TMR_PARAM_READER_WRITE_REPLY_TIMEOUT "/reader/gen2/writeReplyTimeout", uint16_t
TMR_PARAM_READER_WRITE_EARLY_EXIT "/reader/gen2/writeEarlyExit", bool
TMR_PARAM_READER_STATS_ENABLE "reader/stats/enable", TMR_StatsEnable
TMR_PARAM_TRIGGER_READ_GPI "/reader/trigger/read/Gpi", TMR_uint8List
TMR_PARAM_METADATAFLAG "/reader/metadataflags", TMR_TRD_MetadataFlag
TMR_PARAM_LICENSED_FEATURES TMR_PARAM_END TMR_PARAM_MAX
Definition at line 43 of file tmr_params.h.
