Edge defining the cost function for limiting the translational and rotational acceleration. More...
#include <edge_acceleration.h>
Public Member Functions | |
| void | computeError () |
| Actual cost function. | |
| EdgeAccelerationHolonomic () | |
| Construct edge. | |
Detailed Description
Edge defining the cost function for limiting the translational and rotational acceleration.
The edge depends on five vertices
and minimizes: ![$ \min \textrm{penaltyInterval}( [ax, ay, omegadot } ]^T ) \cdot weight $](form_4.png)
.
ax is calculated using the difference quotient (twice) and the x position parts of all three poses
ay is calculated using the difference quotient (twice) and the y position parts of all three poses
omegadot is calculated using the difference quotient of the yaw angles followed by a normalization to [-pi, pi].
weight can be set using setInformation()
penaltyInterval denotes the penalty function, see penaltyBoundToInterval()
The dimension of the error / cost vector is 3: the first component represents the translational acceleration (x-dir), the second one the strafing acceleration and the third one the rotational acceleration.
- See also:
- TebOptimalPlanner::AddEdgesAcceleration
- EdgeAccelerationHolonomicStart
- EdgeAccelerationHolonomicGoal
- Remarks:
- Do not forget to call setTebConfig()
- Refer to EdgeAccelerationHolonomicStart() and EdgeAccelerationHolonomicGoal() for defining boundary values!
Definition at line 474 of file edge_acceleration.h.
Constructor & Destructor Documentation
Construct edge.
Definition at line 481 of file edge_acceleration.h.
Member Function Documentation
| void teb_local_planner::EdgeAccelerationHolonomic::computeError | ( | ) | [inline] |
Actual cost function.
Definition at line 489 of file edge_acceleration.h.
The documentation for this class was generated from the following file:
