#include <grpc/support/port_platform.h>#include <grpc/grpc.h>#include "src/core/tsi/alts/frame_protector/alts_counter.h"#include "src/core/tsi/alts/frame_protector/alts_crypter.h"
Go to the source code of this file.
Classes | |
| struct | alts_record_protocol_crypter |
Typedefs | |
| typedef struct alts_record_protocol_crypter | alts_record_protocol_crypter |
Functions | |
| alts_record_protocol_crypter * | alts_crypter_create_common (gsec_aead_crypter *crypter, bool is_client, size_t overflow_size, char **error_details) |
| void | alts_record_protocol_crypter_destruct (alts_crypter *c) |
| size_t | alts_record_protocol_crypter_num_overhead_bytes (const alts_crypter *c) |
| grpc_status_code | increment_counter (alts_record_protocol_crypter *rp_crypter, char **error_details) |
| grpc_status_code | input_sanity_check (const alts_record_protocol_crypter *rp_crypter, const unsigned char *data, size_t *output_size, char **error_details) |
Typedef Documentation
◆ alts_record_protocol_crypter
| typedef struct alts_record_protocol_crypter alts_record_protocol_crypter |
This file contains common implementation that will be used in both seal and unseal operations. Main struct for alts_record_protocol_crypter that will be used in both seal and unseal operations.
Function Documentation
◆ alts_crypter_create_common()
| alts_record_protocol_crypter* alts_crypter_create_common | ( | gsec_aead_crypter * | crypter, |
| bool | is_client, | ||
| size_t | overflow_size, | ||
| char ** | error_details | ||
| ) |
This method creates an alts_crypter instance, and populates the fields that are common to both seal and unseal operations.
- crypter: a gsec_aead_crypter instance used to perform AEAD decryption. The function does not take ownership of crypter.
- is_client: a flag indicating if the alts_crypter instance will be used at the client (is_client = true) or server (is_client = false) side.
- overflow_size: overflow size of counter in bytes.
- error_details: a buffer containing an error message if the method does not function correctly. It is legal to pass nullptr into error_details, and otherwise, the parameter should be freed with gpr_free.
On success of creation, the method returns alts_record_protocol_crypter instance. Otherwise, it returns nullptr with its details specified in error_details (if error_details is not nullptr).
Definition at line 90 of file alts_record_protocol_crypter_common.cc.
◆ alts_record_protocol_crypter_destruct()
| void alts_record_protocol_crypter_destruct | ( | alts_crypter * | c | ) |
Definition at line 81 of file alts_record_protocol_crypter_common.cc.
◆ alts_record_protocol_crypter_num_overhead_bytes()
| size_t alts_record_protocol_crypter_num_overhead_bytes | ( | const alts_crypter * | c | ) |
For the following two methods, please refer to the corresponding API in alts_crypter.h for detailed specifications.
Definition at line 66 of file alts_record_protocol_crypter_common.cc.
◆ increment_counter()
| grpc_status_code increment_counter | ( | alts_record_protocol_crypter * | rp_crypter, |
| char ** | error_details | ||
| ) |
This method increments the counter within an alts_record_protocol_crypter instance.
- rp_crypter: an alts_record_protocol_crypter instance.
- error_details: a buffer containing an error message if the method does not function correctly or the counter is wrapped. It is legal to pass nullptr into error_details and otherwise, the parameter should be freed with gpr_free.
On success, the method returns GRPC_STATUS_OK. Otherwise, it returns an error status code along with its details specified in error_details (if error_details is not nullptr).
Definition at line 48 of file alts_record_protocol_crypter_common.cc.
◆ input_sanity_check()
| grpc_status_code input_sanity_check | ( | const alts_record_protocol_crypter * | rp_crypter, |
| const unsigned char * | data, | ||
| size_t * | output_size, | ||
| char ** | error_details | ||
| ) |
This method performs input sanity checks on a subset of inputs to alts_crypter_process_in_place() for both seal and unseal operations.
- rp_crypter: an alts_record_protocol_crypter instance.
- data: it represents raw data that needs to be sealed in a seal operation or protected data that needs to be unsealed in an unseal operation.
- output_size: size of data written to the data buffer after a seal or unseal operation.
- error_details: a buffer containing an error message if any of checked inputs is nullptr. It is legal to pass nullptr into error_details and otherwise, the parameter should be freed with gpr_free.
On success, the method returns GRPC_STATUS_OK. Otherwise, it returns an error status code along with its details specified in error_details (if error_details is not nullptr).
Definition at line 32 of file alts_record_protocol_crypter_common.cc.
