Go to the source code of this file.
Macros | |
| #define | REG_CKGR_MCFR (*(__IO uint32_t*)0x400E0624U) |
| (PMC) Main Clock Frequency Register More... | |
| #define | REG_CKGR_MOR (*(__IO uint32_t*)0x400E0620U) |
| (PMC) Main Oscillator Register More... | |
| #define | REG_CKGR_PLLAR (*(__IO uint32_t*)0x400E0628U) |
| (PMC) PLLA Register More... | |
| #define | REG_CKGR_UCKR (*(__IO uint32_t*)0x400E061CU) |
| (PMC) UTMI Clock Register More... | |
| #define | REG_PMC_APLLACR (*(__IO uint32_t*)0x400E0758U) |
| (PMC) Audio PLL Analog Configuration Register More... | |
| #define | REG_PMC_FOCR (*(__O uint32_t*)0x400E0678U) |
| (PMC) Fault Output Clear Register More... | |
| #define | REG_PMC_FSMR (*(__IO uint32_t*)0x400E0670U) |
| (PMC) Fast Startup Mode Register More... | |
| #define | REG_PMC_FSPR (*(__IO uint32_t*)0x400E0674U) |
| (PMC) Fast Startup Polarity Register More... | |
| #define | REG_PMC_IDR (*(__O uint32_t*)0x400E0664U) |
| (PMC) Interrupt Disable Register More... | |
| #define | REG_PMC_IER (*(__O uint32_t*)0x400E0660U) |
| (PMC) Interrupt Enable Register More... | |
| #define | REG_PMC_IMR (*(__I uint32_t*)0x400E066CU) |
| (PMC) Interrupt Mask Register More... | |
| #define | REG_PMC_MCKR (*(__IO uint32_t*)0x400E0630U) |
| (PMC) Master Clock Register More... | |
| #define | REG_PMC_OCR (*(__IO uint32_t*)0x400E0710U) |
| (PMC) Oscillator Calibration Register More... | |
| #define | REG_PMC_PCDR0 (*(__O uint32_t*)0x400E0614U) |
| (PMC) Peripheral Clock Disable Register 0 More... | |
| #define | REG_PMC_PCDR1 (*(__O uint32_t*)0x400E0704U) |
| (PMC) Peripheral Clock Disable Register 1 More... | |
| #define | REG_PMC_PCER0 (*(__O uint32_t*)0x400E0610U) |
| (PMC) Peripheral Clock Enable Register 0 More... | |
| #define | REG_PMC_PCER1 (*(__O uint32_t*)0x400E0700U) |
| (PMC) Peripheral Clock Enable Register 1 More... | |
| #define | REG_PMC_PCK (*(__IO uint32_t*)0x400E0640U) |
| (PMC) Programmable Clock 0 Register More... | |
| #define | REG_PMC_PCR (*(__IO uint32_t*)0x400E070CU) |
| (PMC) Peripheral Control Register More... | |
| #define | REG_PMC_PCSR0 (*(__I uint32_t*)0x400E0618U) |
| (PMC) Peripheral Clock Status Register 0 More... | |
| #define | REG_PMC_PCSR1 (*(__I uint32_t*)0x400E0708U) |
| (PMC) Peripheral Clock Status Register 1 More... | |
| #define | REG_PMC_PMMR (*(__IO uint32_t*)0x400E0730U) |
| (PMC) PLL Maximum Multiplier Value Register More... | |
| #define | REG_PMC_SCDR (*(__O uint32_t*)0x400E0604U) |
| (PMC) System Clock Disable Register More... | |
| #define | REG_PMC_SCER (*(__O uint32_t*)0x400E0600U) |
| (PMC) System Clock Enable Register More... | |
| #define | REG_PMC_SCSR (*(__I uint32_t*)0x400E0608U) |
| (PMC) System Clock Status Register More... | |
| #define | REG_PMC_SLPWK_AIPR (*(__I uint32_t*)0x400E0744U) |
| (PMC) SleepWalking Activity In Progress Register More... | |
| #define | REG_PMC_SLPWK_ASR0 (*(__I uint32_t*)0x400E0720U) |
| (PMC) SleepWalking Activity Status Register 0 More... | |
| #define | REG_PMC_SLPWK_ASR1 (*(__I uint32_t*)0x400E0740U) |
| (PMC) SleepWalking Activity Status Register 1 More... | |
| #define | REG_PMC_SLPWK_DR0 (*(__O uint32_t*)0x400E0718U) |
| (PMC) SleepWalking Disable Register 0 More... | |
| #define | REG_PMC_SLPWK_DR1 (*(__O uint32_t*)0x400E0738U) |
| (PMC) SleepWalking Disable Register 1 More... | |
| #define | REG_PMC_SLPWK_ER0 (*(__O uint32_t*)0x400E0714U) |
| (PMC) SleepWalking Enable Register 0 More... | |
| #define | REG_PMC_SLPWK_ER1 (*(__O uint32_t*)0x400E0734U) |
| (PMC) SleepWalking Enable Register 1 More... | |
| #define | REG_PMC_SLPWK_SR0 (*(__I uint32_t*)0x400E071CU) |
| (PMC) SleepWalking Status Register 0 More... | |
| #define | REG_PMC_SLPWK_SR1 (*(__I uint32_t*)0x400E073CU) |
| (PMC) SleepWalking Status Register 1 More... | |
| #define | REG_PMC_SR (*(__I uint32_t*)0x400E0668U) |
| (PMC) Status Register More... | |
| #define | REG_PMC_USB (*(__IO uint32_t*)0x400E0638U) |
| (PMC) USB Clock Register More... | |
| #define | REG_PMC_VERSION (*(__I uint32_t*)0x400E06FCU) |
| (PMC) Version Register More... | |
| #define | REG_PMC_WMST (*(__IO uint32_t*)0x400E075CU) |
| (PMC) Wait Mode Startup Time Register More... | |
| #define | REG_PMC_WPMR (*(__IO uint32_t*)0x400E06E4U) |
| (PMC) Write Protection Mode Register More... | |
| #define | REG_PMC_WPSR (*(__I uint32_t*)0x400E06E8U) |
| (PMC) Write Protection Status Register More... | |
Detailed Description
Copyright (c) 2015-2018 Microchip Technology Inc. and its subsidiaries.
Definition in file utils/cmsis/same70/include/instance/pmc.h.
Macro Definition Documentation
◆ REG_CKGR_MCFR
| #define REG_CKGR_MCFR (*(__IO uint32_t*)0x400E0624U) |
(PMC) Main Clock Frequency Register
Definition at line 89 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_CKGR_MOR
| #define REG_CKGR_MOR (*(__IO uint32_t*)0x400E0620U) |
(PMC) Main Oscillator Register
Definition at line 88 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_CKGR_PLLAR
| #define REG_CKGR_PLLAR (*(__IO uint32_t*)0x400E0628U) |
(PMC) PLLA Register
Definition at line 90 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_CKGR_UCKR
| #define REG_CKGR_UCKR (*(__IO uint32_t*)0x400E061CU) |
(PMC) UTMI Clock Register
Definition at line 87 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_APLLACR
| #define REG_PMC_APLLACR (*(__IO uint32_t*)0x400E0758U) |
(PMC) Audio PLL Analog Configuration Register
Definition at line 119 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_FOCR
| #define REG_PMC_FOCR (*(__O uint32_t*)0x400E0678U) |
(PMC) Fault Output Clear Register
Definition at line 100 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_FSMR
| #define REG_PMC_FSMR (*(__IO uint32_t*)0x400E0670U) |
(PMC) Fast Startup Mode Register
Definition at line 98 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_FSPR
| #define REG_PMC_FSPR (*(__IO uint32_t*)0x400E0674U) |
(PMC) Fast Startup Polarity Register
Definition at line 99 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_IDR
| #define REG_PMC_IDR (*(__O uint32_t*)0x400E0664U) |
(PMC) Interrupt Disable Register
Definition at line 95 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_IER
| #define REG_PMC_IER (*(__O uint32_t*)0x400E0660U) |
(PMC) Interrupt Enable Register
Definition at line 94 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_IMR
| #define REG_PMC_IMR (*(__I uint32_t*)0x400E066CU) |
(PMC) Interrupt Mask Register
Definition at line 97 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_MCKR
| #define REG_PMC_MCKR (*(__IO uint32_t*)0x400E0630U) |
(PMC) Master Clock Register
Definition at line 91 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_OCR
| #define REG_PMC_OCR (*(__IO uint32_t*)0x400E0710U) |
(PMC) Oscillator Calibration Register
Definition at line 108 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCDR0
| #define REG_PMC_PCDR0 (*(__O uint32_t*)0x400E0614U) |
(PMC) Peripheral Clock Disable Register 0
Definition at line 85 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCDR1
| #define REG_PMC_PCDR1 (*(__O uint32_t*)0x400E0704U) |
(PMC) Peripheral Clock Disable Register 1
Definition at line 105 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCER0
| #define REG_PMC_PCER0 (*(__O uint32_t*)0x400E0610U) |
(PMC) Peripheral Clock Enable Register 0
Definition at line 84 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCER1
| #define REG_PMC_PCER1 (*(__O uint32_t*)0x400E0700U) |
(PMC) Peripheral Clock Enable Register 1
Definition at line 104 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCK
| #define REG_PMC_PCK (*(__IO uint32_t*)0x400E0640U) |
(PMC) Programmable Clock 0 Register
Definition at line 93 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCR
| #define REG_PMC_PCR (*(__IO uint32_t*)0x400E070CU) |
(PMC) Peripheral Control Register
Definition at line 107 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCSR0
| #define REG_PMC_PCSR0 (*(__I uint32_t*)0x400E0618U) |
(PMC) Peripheral Clock Status Register 0
Definition at line 86 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PCSR1
| #define REG_PMC_PCSR1 (*(__I uint32_t*)0x400E0708U) |
(PMC) Peripheral Clock Status Register 1
Definition at line 106 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_PMMR
| #define REG_PMC_PMMR (*(__IO uint32_t*)0x400E0730U) |
(PMC) PLL Maximum Multiplier Value Register
Definition at line 113 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SCDR
| #define REG_PMC_SCDR (*(__O uint32_t*)0x400E0604U) |
(PMC) System Clock Disable Register
Definition at line 82 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SCER
| #define REG_PMC_SCER (*(__O uint32_t*)0x400E0600U) |
(PMC) System Clock Enable Register
Definition at line 81 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SCSR
| #define REG_PMC_SCSR (*(__I uint32_t*)0x400E0608U) |
(PMC) System Clock Status Register
Definition at line 83 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_AIPR
| #define REG_PMC_SLPWK_AIPR (*(__I uint32_t*)0x400E0744U) |
(PMC) SleepWalking Activity In Progress Register
Definition at line 118 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_ASR0
| #define REG_PMC_SLPWK_ASR0 (*(__I uint32_t*)0x400E0720U) |
(PMC) SleepWalking Activity Status Register 0
Definition at line 112 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_ASR1
| #define REG_PMC_SLPWK_ASR1 (*(__I uint32_t*)0x400E0740U) |
(PMC) SleepWalking Activity Status Register 1
Definition at line 117 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_DR0
| #define REG_PMC_SLPWK_DR0 (*(__O uint32_t*)0x400E0718U) |
(PMC) SleepWalking Disable Register 0
Definition at line 110 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_DR1
| #define REG_PMC_SLPWK_DR1 (*(__O uint32_t*)0x400E0738U) |
(PMC) SleepWalking Disable Register 1
Definition at line 115 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_ER0
| #define REG_PMC_SLPWK_ER0 (*(__O uint32_t*)0x400E0714U) |
(PMC) SleepWalking Enable Register 0
Definition at line 109 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_ER1
| #define REG_PMC_SLPWK_ER1 (*(__O uint32_t*)0x400E0734U) |
(PMC) SleepWalking Enable Register 1
Definition at line 114 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_SR0
| #define REG_PMC_SLPWK_SR0 (*(__I uint32_t*)0x400E071CU) |
(PMC) SleepWalking Status Register 0
Definition at line 111 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SLPWK_SR1
| #define REG_PMC_SLPWK_SR1 (*(__I uint32_t*)0x400E073CU) |
(PMC) SleepWalking Status Register 1
Definition at line 116 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_SR
| #define REG_PMC_SR (*(__I uint32_t*)0x400E0668U) |
(PMC) Status Register
Definition at line 96 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_USB
| #define REG_PMC_USB (*(__IO uint32_t*)0x400E0638U) |
(PMC) USB Clock Register
Definition at line 92 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_VERSION
| #define REG_PMC_VERSION (*(__I uint32_t*)0x400E06FCU) |
(PMC) Version Register
Definition at line 103 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_WMST
| #define REG_PMC_WMST (*(__IO uint32_t*)0x400E075CU) |
(PMC) Wait Mode Startup Time Register
Definition at line 120 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_WPMR
| #define REG_PMC_WPMR (*(__IO uint32_t*)0x400E06E4U) |
(PMC) Write Protection Mode Register
Definition at line 101 of file utils/cmsis/same70/include/instance/pmc.h.
◆ REG_PMC_WPSR
| #define REG_PMC_WPSR (*(__I uint32_t*)0x400E06E8U) |
(PMC) Write Protection Status Register
Definition at line 102 of file utils/cmsis/same70/include/instance/pmc.h.
